Steel Telescopic Props Scaffolding Shoring Acrow Prop For Slab Formwork Supporting

Steel Telescopic Props Scaffolding Shoring Acrow Prop For Slab Formwork Supporting

    • Steel Telescopic Props Scaffolding  Shoring Acrow Prop For Slab Formwork Supporting
    • Steel Telescopic Props Scaffolding  Shoring Acrow Prop For Slab Formwork Supporting
  • Steel Telescopic Props Scaffolding  Shoring Acrow Prop For Slab Formwork Supporting

    Product Details:

    Place of Origin: China
    Brand Name: JET
    Certification: BV,CE,ISO
    Model Number: 2200 ~ 4000mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pcs
    Price: negotiable
    Packaging Details: In bundles with steel strip
    Delivery Time: 10 - 15 days
    Payment Terms: T/T, L/C
    Supply Ability: 1000 PCS per day
    Contact Now
    Detailed Product Description
    Material: Q235 Steel Pipe Technique: CO2 Arc Welded
    Color: Dark Red ,orange,blue,silver Surface Treatment: Painted , Galvainzed , Power Coated
    Top/Base Plate: Square Or Flower Or U Head Pin Style: G Pin Or Straight Pin

    Details of Construction Telescopic Scaffold Acrow Prop For Slab Formwork Supporting




    Material: AJ scaffold acrow prop is made of Q235 steel tube, prop nut and thread is casting iron.


    Components: Adjustable steel acrow prop include inner tube, outer tube, prop base plate, prop nut, prop thread and lock pin.


    Surface treatment:Shoring prop can be hot-dip galvanized,dip painted or powder coated.





    we can provide different types and various sizes of telescopic steel prop for you.



    Product Model Middle East Type Spanish Type Italian Type
    prop Inner tube diameter 48mm 40mm 48mm
    Outer tube diameter 60mm 48mm 56mm
    Tube thickness 1.6~3.0mm 1.6~3.0mm 1.6~3.0mm
    Adjustable length

    1600-2900mm

    1800-3200mm

    2000-3500mm

    2200-4000mm

    1600-2900mm

    1800-3200mm

    2000-3600mm

    2200-4000mm


    1600-2900mm

    1800-3200mm

    2000-3600mm

    2200-4000mm






    (1) Steel prop is mainly made of bottom plate, outer tube, inner tube, swivel nut,cotter pin, upper plate

    and the accessories of folding treipod, head jack, the structure is simple and flexible.


    (2) The structure of steel prop is simple, so it is easy to assemble and disassemble.


    (3) Steel prop is adjustable because the inner tube can extend and shrink in the outer tube, so it can be

    adjusted according tothe required height.


    (4) The steel prop can be reused. Even though it is out of work, the material can also be recycled.

    (5) Steel prop can be adjusted according to the different height of the cnstructions.





    How to buy your ideal products?

    You can provide us your drawing, and we will produce as your drawing.Or we can design as your requirements if you do not have a clear plan.



    What is the delivery time?

    It depends on order quantity.Generally, the delivery time will be within 10 to 15 days.


    How about our product quality?

    Our steel prop piles are manufactured with first quality materials


    What is steel quality?

    This system is built from Q235 steel conical pipe with welded blades,and can be applied in a wide variety of different geological locations.
